LS173 Portable Multifunctional Colorimeter With Touch Screens Color Analyzer Lab Values Indication
iProGadgets Repair Tools LS173 Portable Multifunctional Colorimeter With Touch Screens Color Analyzer Lab Values Indication
Features:
Features:
- LS173 is a portable multifunctional colorimeter with D/8° (SCI) optical geometry design
- The color analyzer is equipped with a 3.5-inch IPS color capacitive touch screen, providing an excellent operating experience
- The colorimeter integrates multiple natural color charts, and can quickly match the measured color to the closest color codes
- The color difference meter also has a color difference comparison function, supports a variety of standard color addition methods, the color difference threshold can be set
- The color difference formula can be flexibly selected, which can realize rapid QC testing
- LS173 is usually used in paint, metal, stone, ceramic tiles, and plastics industries for color measurement and management, color difference quality control
- An integrating sphere illuminates the colorimeter diffused light source, which is very suitable for color measurement of high-gloss samples
- Illumination Geometry: D/8, specular component include (SCI)
- Illumination light source: Full spectrum LED light source
- Measuring aperture: 8mm
- Measurement conditions: Light source D65, field of view 10°
- Measuring time: About 1s
- Color space: CIE Lab, Luv, LCh, Yxy, CMYK, RGB, Hex
- Color difference formula: ΔE*ab, ΔE*uv, ΔE*94, ΔE*cmc(2:1), ΔE*cmc(1:1), ΔE*00
- Repeatability: Standard deviation ΔE*ab ≤ 0.03 (Measurement condition: the average value of 30 measurements on the whiteboard at an interval of 3s after calibration)
- Dimension: 86*62.5*158mm
- Power supply: Rechargeable lithium battery3.7V@4000mAh, can measure 10,000 times continuously under full charge
- Display: 480×320 dot matrix IPS color screen
- Language: Simplified Chinese, English
- Charging port: USB (Type-C)
- Operating temperature range: 0~45℃, 0~85%RH (no condensation)
- Storage temperature range: -25~55℃, 0~85%RH (no condensation)
- 1 x Colorimeter
