A-BF SSG-305DS Power Supply Adjustable Programmable Laboratory Bench Power Supply
iProGadgets Repair Tools A-BF SSG-305DS Power Supply Adjustable Programmable Laboratory Bench Power SupplyDual 5-digit LED With Memory Function 30V 5A
Features:
Specification:
Package includes:
Features:
- Double five-digit display for voltage, current, and power
- Automatic test function ‘PASS/FAIL’ result display
- Settable time output automatically shuts down
- Input wide-voltage, supports AC110/220V switching global voltage
- Intelligent temperature control fan
- High resolution and high accuracy
- OVP over-voltage protection/OCP over current protection
- Operation using rotary coding switches
- Output on/off control button
- Customizable 4 groups of store/recall settings
- Fully digital output value setting
- The key lock function prevents misoperation
- Built-in buzzer as warning prompt
Specification:
- Model: SSG-305DS
- AC Input: Voltage: 200-240V; Current: 2.2A
- DC Output: Voltage: 0-30V; Current: 0-5A
- Maximum output power: 150W
- Input regulation rate: Voltage: 0.02%+5mV; Current: 0.01%+5mA
- Power factor: >0.75
- Load regulation: Voltage: <0.01%+5mV; Current: <0.01%+5mA
- Measurement error: Voltage: 0.05%*FS+0.1%*RD 0.05%*Full range +0.1%*Measured value; Current: 0.05%*FS+0.1%*RD 0.05%*Full range +0.1%*Measured value
Output Ripple:
- Voltage peak: 0.2%*FS+30mV 0.1%*Full range 30mV
- Voltage Average: 0.2%*FS+10mV 0.1%*Full range 10mV
- Current average: 0.2%*FS+20mA 0.1%*Full range 20mA
- Efficiency at full load (220V AC input): ≥85%
- Programming resolution: Voltage: 1mV; Current: 1mA
- Programming accuracy: Voltage: 20mV; Current: 5mA
- Temperature Coefficient: Voltage: 50ppm/℃; Current: 100ppm/℃
- Protective function: OVP: 32V; OCP: 5.5A; OPP: 160W; OTP: 85℃
- Output response time: Rising no-load: <50ms; Rising full load: <80ms; Lowering no-load: <800ms; Lowering full load: <15ms
- Remote voltage compensation: Optional
- Maximum compensation voltage: 2V
- Communication interface: Without a communication interface
- Fan temperature control: Infinitely variable speed
- Work environment temperature: 5-40°C
Package includes:
- 1 x Power Supply
- 1 x Power Cable
